Why Subnetting Exists
IPv4 addresses are 32-bit numbers — about 4.3 billion total. That sounds like a lot until you consider that the internet has billions of connected devices. The solution, before IPv6 becomes universal, is to be efficient: break address space into appropriately-sized chunks rather than handing out large blocks to organisations that will waste most of them.
Subnetting also improves network design. A single flat network of 1,000 devices generates broadcast traffic that reaches all 1,000 devices simultaneously. Divided into subnets of 50–100 devices each, broadcasts are contained. Routing becomes cleaner. Troubleshooting becomes faster. Security boundaries become possible.
The Binary Foundation
An IPv4 address like 192.168.1.100 is really four 8-bit numbers (octets) written in decimal for human convenience. In binary: 11000000.10101000.00000001.01100100. Every IP address is 32 bits.
A subnet mask defines which portion of the address is the network and which is the host. 255.255.255.0 in binary is 11111111.11111111.11111111.00000000 — the first 24 bits are network, the last 8 are host. This is written in CIDR notation as /24.
CIDR Notation
CIDR (Classless Inter-Domain Routing) notation writes an address with a slash and the number of network bits: 192.168.1.0/24. The /24 means 24 bits are network, leaving 8 bits for hosts — which gives 2⁸ = 256 addresses, minus 2 (network address and broadcast) = 254 usable hosts.
Common subnet sizes:
- /24 — 254 hosts. Standard office network.
- /25 — 126 hosts. Half a /24.
- /26 — 62 hosts. Quarter of a /24.
- /27 — 30 hosts. Small segment.
- /28 — 14 hosts. Small VLAN or DMZ.
- /30 — 2 hosts. Point-to-point links between routers.
- /32 — 1 host. Loopback addresses, host routes.
The formula: 2^(32 - prefix) - 2 = usable hosts. For /26: 2^(32-26) - 2 = 2^6 - 2 = 64 - 2 = 62.
Network Address and Broadcast
Every subnet has two reserved addresses you cannot assign to hosts:
The network address is the first address — all host bits set to zero. For 192.168.1.0/24, the network address is 192.168.1.0. It identifies the subnet itself in routing tables.
The broadcast address is the last address — all host bits set to one. For 192.168.1.0/24, the broadcast is 192.168.1.255. Frames sent to this address are delivered to all devices in the subnet.
The usable range is everything in between: 192.168.1.1 → 192.168.1.254.
Subnetting a /24 — A Practical Example
You have 192.168.10.0/24 and need to create 4 equal subnets. You need to borrow bits from the host portion. To create 4 subnets you need 2 bits (2² = 4). Move the prefix from /24 to /26.
The four /26 subnets:
- 192.168.10.0/26 — Network: .0, Broadcast: .63, Hosts: .1–.62
- 192.168.10.64/26 — Network: .64, Broadcast: .127, Hosts: .65–.126
- 192.168.10.128/26 — Network: .128, Broadcast: .191, Hosts: .129–.190
- 192.168.10.192/26 — Network: .192, Broadcast: .255, Hosts: .193–.254
The block size is 64 (256 ÷ 4). Each subnet starts 64 addresses after the previous one. This pattern is the shortcut: block size = 256 - subnet mask last octet. For /26, mask = 255.255.255.192, block size = 256 - 192 = 64.
Variable Length Subnet Masking (VLSM)
VLSM allows different subnets of different sizes within the same address space — matching subnet size to actual need rather than assigning uniform blocks. A department of 100 users gets a /25 (126 hosts). A server segment of 10 gets a /28 (14 hosts). A point-to-point WAN link gets a /30 (2 hosts). No addresses wasted.
VLSM requires that your routing protocol supports it — OSPF, EIGRP, and BGP all do. RIPv1 does not (legacy, avoid).
Private Address Ranges
RFC 1918 defines three ranges reserved for private use — not routable on the public internet:
- 10.0.0.0/8 — 16.7 million addresses. Large enterprises.
- 172.16.0.0/12 — 1 million addresses. Medium organisations.
- 192.168.0.0/16 — 65,536 addresses. Home and small office.
These addresses require NAT to reach the internet. Use 10.0.0.0/8 for large enterprise designs — it gives you maximum flexibility. Avoid 192.168.1.0/24 in enterprise contexts (it clashes with home routers and creates VPN headaches).
The Mental Model That Makes It Stick
Think of an IP address space as a street. /8 is the city. /16 is the neighbourhood. /24 is the street. /28 is a few houses on that street. The prefix length tells you how specific the address is — longer prefix, smaller block, more specific location. This hierarchy is what makes routing work: routers match the longest (most specific) prefix in their table to forward packets efficiently.
